Plasma Gantry Machine Parts , Rail Track for Sale

FOB Reference Price:Get Latest Price
US $70-150 / Unit | 1 Unit/Units (Min. Order)
Supply Ability:
5000 Piece/Pieces per Month
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Longteng
Model Number:
LT-LG-02
Product name:
rail
Material:
steel
Application:
cnc machine
Certification:
CE ISO
Package:
Wooden case
Loading port:
FOB Shanghai
Packaging & Delivery
Packaging Details
Carton,Wooden case
Delivery Time
5-15 days after payment

Rail And Rack For CNC Gantry Plasma / Flame Cutting Machine



1) Description:


This rail is the part which use for the CNC gantry Cutting machine which include the H Type support rail beam, big and small base plate, left and right adjustment bolt, the first nut, pressing plate bolt, high and low bolt. The mentioned big and small base plate welding on the H beam support rail beam for support the rail; the big and small base plate has the left and right adjustment bolt and first nut to adjust the left and right position of the rail; the mentioned big and small base plate has the fixed bolt which could compress the rail, the rail has the high and low adjustment bolt to adjust the high and low position of that.



Above that all, the connection place insert the tie rod, use bolt, the second nut and the joint ring for fixing, which could achieve the gantry CNC machine for the stable moving and the high precision.



2) Specifications:

Model

Length1

Length 2

Top Width

Base Width

Height

24KG

2 meter

3 meter

45mm

88mm

103mm

38KG

2 meter

3 meter

55mm

108mm

120mm

43KG

2 meter

3 meter

55mm

108mm

133mm

50KG

2 meter

3 meter

55mm

125mm

142mm



3)Maintenance Skills:
1. Replace the consumbles in time before completely damaged.
2. Avoid the collision of the torch height controller.
3. Keep the connection threads clean.
4. Check if there are loose parts.
